4S 8A lifepo4 12.8V 18650 BMS PCM battery protection board bms

4S 8A lifepo4 12.8V 18650 BMS PCM battery protection board bms pcm for lifepo4 battery cell pack with balancing
- This BMS used Japan lifepo4 rechargeable battery protection IC It can also used for 4s battery packs.
- 1) high-accuracy voltage detection circuit;
- 2) terminal of the charger using high voltage device;
- 3) Built-in three-stage over-current detection circuit (over-current 1, over-current 2, or load short circuit);
- 4) MOS transistor can control the battery charge and discharge; 5) low standby current consumption.
3S BMS Connection instruction:
B+ connected battery positive;
B1 connect the point between 1 and battery 2;
B2 connect the point between battery 2 and battery 3;
B3 connect the point between battery 3 and battery 4
B- connect battery negative end
P- connection charge/discharge negative
P+ connect charge /discharge positive
Notice:
1) Please note that the input and output voltage, and load current conditions for power protection board does not exceed the electrical parameters of the allowable power consumption;
2) special attention to the load current can not work long hours between maximum continuous operating current and over-current protection current;
3) When connecting the battery ,it may not discharge. In this case, connect the charger can be restored to normal working condition;
4) Although the BMS built-in electrostatic protection circuit, but please do not hand touch when BMS in the working condition, so as to avoid damage from static electricity protection board.
