Dwyer® Portable Static Pr Tip, A-303, for 3/16" Plastic/Rubber Tubing, 4" (101 mm) Insertion Depth

R 1,102

or 4 x payments of R275.50 with Payflex

Payflex

Availability: Currently in Stock

Delivery: 10-20 working days

Option Currently Selected: ?ne ???k

Variations

Dwyer® Portable Static Pr Tip, A-303, for 3/16" Plastic/Rubber Tubing, 4" (101 mm) Insertion Depth
- Tube Connection Size: 3/16"
- Connection Type: Plastic or Rubber
- Insertion Depth: 4" (101mm)
- Material: Brass
These sensors are for use with Manometers, MagnehelicÂ® Gages, Pressure Switches and other Controllers to pick up or sense static pressure drop across air filters and cooling coils, blower input and discharge pressures, etc. The angled tips shown have 4" insertion depth. Each has four radially drilled .040" sensing holes. All except Model A-303 mount in 3/8" hole in duct. For portable use, a magnet holds No. A-303 in place. No. A-305 is used where a very low actuation or sensing point is required on a pressure switch or gage or where response time is critical. No. A-307 and A-308 are suitable for use in low velocity systems or where the need for accuracy is less critical.
Country USA
Brand Dwyer
Manufacturer Dwyer Instruments
Binding Misc.
ItemPartNumber A-303
Model A-303
Size Оne Расk
UnitCount 1
UPCs 692579202550
EANs 0692579202550
ReleaseDate 0000-00-00
