ZHC Solar Charge Controller 20A/30A for Lithium Battery with

ZHC Solar Charge Controller 20A/30A for Lithium Battery with USB, LCD (20A, 12V / 24V)
- Support Variou Kinds of Battery: Lithium Battery, Gel Battery, Car Battery, Even Old Battery, Etc.
- Intelligent PWM Charge Mode , 12V/24V Self Adaptive.
- Simple Control: LCD Display Operation Data, Working Condition, Switch Load Control Modes, Energy Statistics.
- Temperature Compensation Function, Multiple Load Operation Mode
- Battery Protections: Battery Back Discharge Protection, Low-Voltage Protection, Transposition Protection, OverLoad and Short-Circuit Protection
SL03 Series Controllers are kinds of intelligent multi-functional solar charge and discharge controller. this series adopts the new 32 bits microprocessor to collect and compute various parameters, which is much more accurate and speedy than the former 8 bit microprocessor, the customized LCD with wide temperature range is with vivid operation interface. the latest proprietary technology solves the problem of voltage display of solar panel. nearly all parameters can be shown and set up flexibly. all of the multi-meter and other voltage and current instruments can be replaced by this controller, which can satisfy your various demands.

Speficication

Model: 20 Amp Solar Charge Controller
Max Charge Current: 20A
Max Load Current: 20A
Max Voltage of Lolar Panel: <50V
Work Voltage:12V/24V Auto Discriminating
Stop-Charge-Voltage: default 14.4V/28.8V (8V-35V Settable)
Float-Charge-Voltage: default 13.6V/27.2V (8V-35V Settable)
Low Voltage Reconnected: default 12.4V/24.8V (8V-35V Settable)
Low Voltage Disconnection: default 10.8V/21.6V(8V-35V Settable)
No Load Losses Current:<15mA
Over-load and Short Circuit: 1.1 times of max current, works for 5 seconds or Short circuit,the load is off at once and the indicator icon flashing,Then wait 30second , it will automatically restart to work.
Country USA
Brand ZHC
Manufacturer ZHC
Color 12V / 24V
Size 20A
EANs 7907613248443
ReleaseDate 0000-00-00

Country	USA
Brand	ZHC
Manufacturer	ZHC
Color	12V / 24V
Size	20A
EANs	7907613248443
ReleaseDate	0000-00-00
